Liquid Bins




Optimum offers a wide range of bins and tanks to securely store liquids. We build with high quality mild and/or Stainless steels and use an advanced leak testing formula to ensure years of trouble free service.
Standard options
- Bolt-on Bottom Flange with 2 Couplings
- Spring Top Lid
- Bolt-on Side and Roof Ladder
- Level Indicator Tube
Tonnage is based on 62lbs/cu.ft.
Model # | IMP Gallons | US Gallons | Liters | Cubic Feet | Short Tons | Metric Tons | Bin Height |
510-15L | 1,321 | 1,587 | 6,008 | 212 | 6.6 | 6.0 | 14’3″ |
610-40L | 1,931 | 2,319 | 8,781 | 310 | 9.6 | 8.7 | 14’9″ |
705-40L | 1,629 | 1,956 | 7,405 | 261 | 8.1 | 7.4 | 11’9″ |
710-40L | 2,827 | 3,395 | 12,855 | 453 | 14.1 | 12.7 | 16’9″ |
905-40L | 2,896 | 3,478 | 13,166 | 464 | 14.4 | 13.0 | 13’4″ |
1010-40L | 6,147 | 7,382 | 27,945 | 986 | 30.6 | 27.8 | 19’1″ |
1012-40L | 7,125 | 8,557 | 32,393 | 1143 | 35.5 | 32.1 | 21’1″ |
1020-40L | 11,039 | 13,257 | 50,185 | 1772 | 54.9 | 49.8 | 29’1″ |
1210-40L | 9,213 | 11,064 | 41,885 | 1479 | 45.9 | 41.6 | 20’7″ |
1225-40L | 19,780 | 23,755 | 89,923 | 3175 | 98.4 | 89.3 | 35’7″ |
1415-45L | 18,187 | 21,841 | 82,678 | 2920 | 90.5 | 82.1 | 28’3″ |
1612-40L | 20,169 | 24,222 | 91,692 | 3237 | 100.3 | 91.1 | 25’10” |
1615-40L | 23,927 | 28,734 | 108,772 | 3841 | 119.1 | 108.0 | 28’10” |
1617-40L | 26,431 | 31,742 | 120,159 | 4244 | 131.6 | 119.4 | 30’10” |
1620-40L | 30,188 | 36,256 | 137,239 | 4847 | 150.3 | 136.3 | 33’10” |
1622-40L | 32,693 | 39,262 | 148,626 | 5289 | 164.0 | 148.8 | 35’10” |
1625-40L | 36,450 | 43,775 | 165,706 | 5851 | 181.4 | 164.6 | 38’10” |
1627-40L | 38,955 | 46,783 | 177,093 | 6253 | 193.8 | 175.9 | 40’10” |
1630-40L | 42,712 | 51,295 | 194,174 | 6857 | 212.6 | 192.9 | 43’10” |
